Food Processing Cleanroom European Crane

1. European crane product introduction:
The European-style crane has the advantages of light weight, compact structure and low energy consumption. A trolley and a hoisting mechanism are set on the bridge. The trolley can run forward and backward, and the cart can run and other mechanisms to realize the transportation of materials and objects in a three-dimensional space. The European-style crane adopts the design concept, with small size, light weight and small wheel pressure. Compared with traditional cranes, the distance from the hook to the wall is small and the clearance height is low. The European crane can work closer to the front and has a higher lifting height, which actually increases the effective working space of the existing workshop. Since European cranes have the characteristics of light weight and small wheel pressure, the new workshop space can be designed to be smaller and more functional.
Our European cranes are of reliable quality, good versatility, low cost, compact structure, light weight, energy saving and low noise. A new definition of gantry cranes.
The concept of European cranes was formed in recent years, the purpose is to be different from the traditional cranes in the past. Mainly include: bridge cranes, gantry cranes, cantilever cranes, flexible beam cranes, explosion-proof cranes and other industrial cranes.
2. Structural characteristics of European cranes:
1. Main beam part
1. The main beam adopts square box steel structure design;
2. The main welds are all subjected to non-destructive testing;
3. The steel plate material is general steel (Q235B);
4. The vertical winding is according to the industry standard;
5. The steel plate is pretreated by shot blasting to achieve Sa2.5 standardization;
6. Carefully check and clean the steel plate before welding, usually by automatic welding machine (MIG or semi-automatic welding).
Second, the end beam part
1. The end beam is welded and formed by rectangular steel pipe or steel plate, and the formed end beam is positioned and processed in a CNC machine tool to achieve the allowable deviation range and ensure dimensional accuracy and matching tolerance;
2. The end beam is equipped with double rim wheels, buffers and anti-railing protection devices;
3. A maintenance platform (maintenance aisle) is arranged on the driving side of the trolley along the main beam direction of the double-girder crane;
4. The main beam and the end beam are connected by high-strength bolts to ensure the precision and smooth operation of the whole machine.
